class HMdcCal2ParSim: public HParSet

 constructor

 destructor

 intitializes the container from an input

 This function calculates the drift time for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the Error of drift time1 for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the drift time for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.
 Time1 and Error of Time1 (no random smearing) are returned to Float pointers

 This function calculates the drift time for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the Error of drift time1 for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the drift time2 for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the Error drift time2 for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the drift velocity for a given distance
 to sense wire and impact angle. Vd [mu/ns] = deltaT1/deltaDist

 This function calculates the reslution in nm for a given distance
 to sense wire and impact angle. Res[nm]=timeErr/Vd.

 This function calculates the drift time for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 This function calculates the drift time for a given distance
 to sense wire.A Interpolation between the two closest angle steps
 is performed and the drift time value returned.
 Input is the angle of the track (alphaTrack:90 degree for perpendicular impact),which
 has to be recalculated to the angle of minimum drift distance (alphaDrDist:0 degree for
 perpendicular impact).
   y ^
     |  |------------*----|              cathod  plane
     |  | cell        *   |
     |  |            / *  |
     |  |           /90 * |
     |  | driftDist/     *|
     |  |         / |     *
   --|--|--------*^-|-----|*--------->   sense/potential plane
     |  |           |     | *        x
     |  |      alphaDrDist|  *
        |                 |/  *          alphaDriftDist=90-alphaTrack
        |      alphaTrack /    *
        |-----------------|     * track  cathod plane

 angles must be between 0 and 90 degree, all other angles have to be shifted
 before calling the function.

 fills arrays of MdcCal2Par (time) from arrays of MdcCal2ParSim (distance)

 plots data into TGraphErrors for time1 and time2 including errors

 Plots data into 2d-Hists
 type = 0 ->time1
 type = 1 ->Error time1
 type = 2 ->time2
 type = 3 ->Error time2

 writes the container to an output

 decodes one line read from ascii file I/O and calls HMdcCal2ParAngleSim::fillTime1(...)

 puts the ascii header to the string used in HMdcParAsciiFileIo

 writes one line to the buffer used by ascii file I/O

 clears the container

 prints the container

 Stream an object of class HMdcCal2ParSim.
