class HShowerDigitizer: public HReconstructor

_HADES_CLASS_DESCRIPTION


  HShowerDigitizer digitizes data, puts output values into
  HShowerRawMatr data category. The input data are read from the HGeantShower
  category. The Shower digitization is split into several tasks as shown
  in the flow diagram below.


HShowerUnpacker
|   (embedding mode)   | \
|                      |  \      ------------------
----------------------   |     |  HGeantShower    |
|      ------------------\
|                         \
|      ------------------  \------------->  ----------------------
|  HGeantWire      |   <------------ |  HShowerHitDigitizer
|      ------------------\                  ----------------------
|                         \
------------------  \------------->
-- | HShowerRaw  |   |  HShowerRawMatr  |   <------------ |  HShowerPadDigitizer  |
    -------------     ------------------\                 |( creates track objects
\                |  for real tracks in
----------------------          ------------------  \               |  embedding mode too)  |
|   HShowerCalibrater  |        |  HShowerTrack    |  \<------------  -----------------------
|   (embedding mode)   |         ------------------\   \

------------------  \   ----------> |   HShowerCopy
-------------------> |  HShowerCal      |  \<------------ |(add charge of real hit|
------------------\   \             | in embedding too )    |
\   \             -----------------------
----\--------->
HShowerHitHdr   |   <--\--------- |  HShowerHitFinder
\
------------------         \        |
  HShowerPID      |   <-----\-------
------------------           \      |
------------------            \     |
  HShowerHit      |   <--------\----
------------------ \            \

\------------->
HShowerHitTrack |   <------------ | HShowerHitTrackMatcher



  In the case of TRACK EMBEDDING of simulated tracks into
  experimental data the real data are written by the HShowerUnpacker into
  HShowerRaw category. The real hits are taken into
  account by the digitizer (adding of charges). The embedding mode is recognized
  automatically by analyzing the
  gHades->getEmbeddingMode() flag.
            Mode ==0 means no embedding
                 ==1 realistic embedding (first real or sim hit makes the game)
                 ==2 keep GEANT tracks   (as 1, but GEANT track numbers will always
                     win against real data. besides the tracknumber the output will
                     be the same as in 1)
